Automatic Velux Window

❶Dual Servo Motors for Glass Sash

Two symmetric closed-loop servo motors adopt pulse coding for millimeter precise positioning with soft start-stop buffer to avoid shake. It locks at any height and bounces back to prevent pinching obstacles. Compatible with smart home linkage and remote control; a manual clutch enables emergency opening without electricity to avoid operation failure during power outages.

❷Custom High-Precision Profiles

Purified 6063-T5 aluminum is extruded into double nested multi-cavity profiles designed for vertical lifting force, resisting twist and crack during long-term repeated movement. Triple-coat fluorocarbon finish resists coastal corrosion and UV fading. Reinforced inner liners for long vertical sections greatly improve wind pressure resistance for high-rise and tall opening installation.

❸Separate Dual Servo Motors for Screen

An independent dual-servo drive group works separately from glass motors, allowing screen lowering alone for insect prevention while the window stays open for ventilation. Built-in overheat and overcurrent protection prevents motor burnout. It auto locks at bottom and retracts fully into top frame to keep facade minimalist with no exposed mesh.

❹Multi-Layer Tempered Insulated Glass

Standard 5mm+20A+5mm 3C certified insulated tempered glass filled with argon gas to reduce noise and heat transfer. Optional offline Low-E coating cuts solar heat gain in summer and retains indoor warmth in winter. Flexible edge wrapping buffers vibration during lifting, and broken glass forms blunt particles to eliminate injury risks for high-mounted windows.

❺Split Wide Thermal Break Strips

Split widened PA66GF25 glass fiber thermal strips run through the full frame to match nested profile structure and block thermal bridges more thoroughly than single strips. Alkali-free fiber filler prevents thermal deformation and cracking. Matched with layered gaskets, it slows metal heat conduction obviously and stabilizes indoor temperature in extreme weather with remarkable energy saving effect.

❻One-Piece Bent Hollow Aluminum Spacer

CNC one-piece bent aluminum spacer has no splicing gaps to block vapor infiltration fundamentally. Pre-filled 4A molecular sieve continuously absorbs residual moisture inside the glazing cavity, permanently avoiding fogging and condensation inside insulated glass under drastic temperature difference and humid climate for far longer service life.

❼Constant Pressure Injection Corner Craft

Constant pressure high-pressure glue injection fills all hollow miter corners and integrates separate profiles into one rigid unit after curing. It doubles tensile and torsion resistance against repeated vertical pulling force from motors, eliminating corner gap water leakage caused by long-term lifting operation and fully sealing all splicing seams.

❽Dedicated Interlock Locking Hardware

Custom interlock hardware engages multi-point locks automatically when the window closes without manual operation. Stainless steel parts with electrophoretic anti-rust treatment resist outdoor humidity and UV aging. Built-in anti-fall latches lock the sash instantly once motors fail to prevent falling hazards for high installation positions.
